For water supply from wells or reservoirs.
For domestic use,for civil and industrial applications.
For garden use and irrigation.
Maximum fluid temperature up to +40℃.
Maximum sand content:0.25%.
Rewindable motor
Three-phase:380V-415V/50Hz
Single-phase:220V-240V/50Hz
Special mechanical seal
Other voltages or frequency 60 Hz
(according to our general sales conditions).
| MODEL | P₂ |
Outlet (inch) |
Capacity (m3/h) |
Head (m) |
N.W (kg) |
Packing dimension (mm) |
||
| 1~220V/240V | 3~380V/415V | KW | HP | |||||
| QDX1.5-17-037 | - | 0.37 | 0.5 | 1" | 1.5 | 17 | 9.5 | 420×225×190 |
| QDX1.5-33-0.75 | QX1.5-33-0.75 | 0.75 | 1.0 | 1" | 1.5 | 33 | 14.5 | 460×300×240 |
| QDX3-20-0.55 | - | 0.55 | 0.75 | 1" | 3 | 20 | 12.5 | 460×300×240 |
| QDX3-30-1.1 | QX3-30-1.1 | 1.1 | 1.5 | 1" | 3 | 30 | 17.3 | 500×300×240 |
| QDX6-20-0.75 | QX6-20-0.75 | 0.75 | 1.0 | 1½" | 6 | 20 | 14.5 | 460×300×240 |
| QDX6-26-1.1 | QX6-26-1.1 | 1.1 | 1.5 | 1½" | 6 | 26 | 17.3 | 500×300×240 |
| QDX10-12-0.55 | - | 0.55 | 0.75 | 1½" | 10 | 12 | 13.2 | 460×300×240 |
| QDX10-18-0.75 | QX10-18-0.75 | 0.75 | 1.0 | 2" | 10 | 18 | 14.5 | 460×300×240 |
| QDX15-7-0.55 | - | 0.55 | 0.75 | 2" | 15 | 7 | 13.2 | 460×300×240 |
| QDX15-10-0.75 | QX15-10-0.75 | 0.75 | 1.0 | 2" | 15 | 10 | 14.5 | 460×300×240 |
| QDX15-15-1.1 | QX15-15-1.1 | 1.1 | 1.5 | 2" | 15 | 15 | 16.7 | 500×300×240 |
| QDX15-18-1.5 | QX15-18-1.5 | 1.5 | 2.0 | 2" | 15 | 18 | 18 | 500×300×240 |
| QDX25-10-1.1 | QX25-10-1.1 | 1.1 | 1.5 | 2½" | 25 | 10 | 19 | 545×315×270 |
| QDX25-12-1.5 | QX25-12-1.5 | 1.5 | 2.0 | 2½" | 25 | 12 | 21.6 | 545×315×270 |
| QDX30-6-0.75 | QX30-6-0.75 | 0.75 | 1.0 | 3" | 30 | 6 | 15.7 | 460×300×240 |
| QDX40-6-1.1 | QX40-6-1.1 | 1.1 | 1.5 | 3" | 40 | 6 | 19 | 545×315×270 |
| QDX40-9-1.5 | QX40-9-1.5 | 1.1 | 1.5 | 3" | 40 | 9 | 21.6 | 545×315×270 |
